Medical Product Packaging Heat Sealers

Accu-Seal’s medical impulse and constant heat sealers offer the features, performance, and reliability to satisfy the demands of medical packaging applications.

Temperature control and password protected seal parameters allow PQ/OQ process validation and compliance with ISO 11607 packaging standards. Available with vacuum and gas purge capability, our sealers are compatible with a variety of bag materials, including polyethylene (LDPE), polypropylene, HDPE, Tyvek, foil lamination, Mylar, Nylon, and others.

Compare the sealers below:

Model 8000 Compact Pneumatic Impulse Heat Sealer

Model 8000 medical pouch heat sealer is ideal for medical, lab, and pharmaceutical product packaging requirements where space, performance, and flexibility are critical. The unique “Quick-Release” vacuum and seal bar plates facilitate quick removal for cleaning and maintenance. Available with single or multiple nozzle configurations, process alarm settings, multiple operating modes, password protected seal parameter recipes, and selectable upper heat or both upper and lower heat. RoHS compliant design also provides for process validation (ISO 11607), calibration ready, and available with CE compliance.

Available in Seal only or Gas-Vacuum configurations.

675TC2 Open Jaw Pneumatic Impulse Sealer

The Model 675TC2 heat sealer delivers equivalence throughout your facility with repeatable, reliable performance. Featuring open-ended seal bar design, the 675TC2 integrates gas purge and vacuum, process alarm settings, multiple operating modes and password protected seal parameter recipes. A user-friendly LCD touch screen and high speed PLC provide the confidence that all process parameters are maintained seal-to-seal. Available with Upper seal bar heat, or both Upper and Lower seal bar heating. Seal only configuration available.

Available in Seal only or Gas-Vacuum configurations.

Model 6300SP Heat Sealer- Impulse Heat

Model 6300SP is designed specifically for pouch sealing applications requiring process validation. Integrates a high-resolution HMI digital display, heavy-duty seal bar, and actuator assembly, temperature control, process alarm settings, and password protected seal parameter recipes. Available with Upper seal bar heat, or both Upper and Lower seal bar heating. Validatable and calibratable across all seal parameters, ISO 11607, CE compliant. Available with CE compliance.

Model 5300SP Bag and Pouch Sealer- Impulse Heat

Model 5300SP is a budget, user-friendly heat sealer with lower seal bar heating. Seamless stainless steel enclosure, product support tray, and 3/8” seal width are standard features on this machine. Password protected recipe, digital process control, and high speed PLC with LCD touchscreen HMI provide assurance that process parameters are maintained to deliver equivalence throughout your facility, with repeatable, reliable performance. Validatable and calibratable across all seal parameters to ISO 11607. Designed to meet Cleanroom packaging requirements for sealing a variety of pre-made pouch materials. CE compliant.

Model 6400SP Pouch Sealer- Constant Heat

Constant Heat Medical Pouch Sealer assures the highest level of process control. Digital high-speed PLC controller allows for customized programming of seal temperature, time, and pressure. Two-level password protection requires supervisor password override for abnormal seal temperature profile, jaw obstruction and seal pressure. Seal lengths up to 20” (50.8 cm).

Model 830 Modular Heat Sealer

Provides flexibility to arrange a sealing station with a remote tabletop seal head. Perfect for laminar flow hoods and small work areas. Digital HMI touchscreen is mounted on a flexible arm for easy access and visibility. The control cabinet can be remotely located from the seal head assembly. Optional stand mounting for sealing in a vertical, horizontal or angled position.

HDMP3-TC Heavy Duty Pneumatic Impulse Sealer

For large product packaging that requires tight process control, the HDMP3TC seals bags up to 50 inches in length. The HDMP3TC offers open-ended seal bars with wide jaw opening for ease of bag entry and positioning. Can operate on a sturdy horizontal tabletop or can be stand-mounted for orientation in the vertical position. Password protected alarm and seal parameter settings, digital PLC control, with multiple operating modes and recipe programs.

Available in Seal only or Gas-Vacuum configurations.
